External Reference Parameters
FQ2 User’s Manual
437
Appendices
12
124 Model
region
Reference X Setting/Acqui-
sition
0 to 99,999.9999 0 --- ---
125 Reference Y Setting/Acqui-
sition
0 to 99,999.9999 0 --- ---
145 Detec-
tion coor-
dinate
Detection point X Setting/Acqui-
sition
0 to 9,999 0 --- ---
146 Detection point Y Setting/Acqui-
sition
0 to 9,999 0 --- ---
147 Mea-
sure-
ment
condi-
tions
Sub-pixel Setting/Acqui-
sition
0: No, 1: Yes 0 --- ---
148 Candidate level Setting/Acqui-
sition
0 to 100 70 --- ---
166 Judge-
ment
condi-
tions
Judgement upper limit
for correlation
Setting/Acqui-
sition
0 to 100 100 --- Adjust judge-
ment
167 Judgement lower limit
for correlation
Setting/Acqui-
sition
0 to 100 60
310 Logging
condi-
tions
Data logging switch for
entire unit
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
311 Data logging switch for
judgement
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
312 Data logging switch for
scroll X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
313 Data logging switch for
scroll Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
315 Data logging switch for
position X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
316 Data logging switch for
position Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
321 Data logging switch for
correlation
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
700 Display
settings
Position compensation
X display
Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
701 Position compensation
Y display
Se
tting
/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
702 Correlation display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
703 Position X display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
704 Position Y display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
