Omron fq2

Menu Tables
FQ2 User’s Manual
409
Appendices
12
Inspection
Settings
Judgement Scene ---
(Search, Shape search II, Sensitive search)
Detection
No.
If you enabled the output of multiple
results, you can specify the results to dis-
play.
--- Scene p. 96,
p. 106,
p. 114
Correlation Sets the correlation OK range. 0 to 100 (Defaults: Lower limit: 0, Upper
limit: 100)
Scene
Position X Sets the position OK range. (Defaults: Lower limit: −99,999.9999,
Upper limit: 99,999.9999)
Scene
Position Y (Defaults: Lower limit: −99,999.9999,
Upper limit: 99,999.9999)
Scene
Angle Sets the angle OK range. −180 to 180 (Defaults: Lower limit: −180,
Upper limit: 180)
Scene
Count Sets the count OK range. 0 to 32 (default: 0) Scene
(Edge position)
Position X Sets the position OK range. −99,999.9999 to 99,999.9999
(Defaults: Lower limit: −99,999.9999,
Upper limit: 99,999.9999)
Scene p. 121
Position Y −99,999.9999 to 99,999.9999
(Defaults: Lower limit: −99,999.9999,
Upper limit: 99,999.9999)
Scene
(Edge width)
Edge width Sets the Edge width OK range. • When the result type is set to relative
values:
Range: −99,999.9999 or 99,999.999
Default: Upper limit: 99,999.9999, Lower
limit: −99,999.9999
• When the result type is set to ratios:
Range: 0.000 to 999.9999(%)
Default: Upper limit: 999.9999, Lower
limit: 0.000
Scene p. 128
(Edge pitch)
Edge pitch Sets the Edge pitch OK range. Range: 0 to 1000
Defaults: Lower limit: 0, Upper limit: 1000
Scene p. 132
Average
pitch
Range: 0.0000 to 99,999.9999
Defaults: Lower limit: 0.0000, Upper limit:
99,999.9999
Scene
Max. pitch
(maximum
pitch)
Scene
Min. pitch
(minimum
pitch)
Scene
Average
width
Scene
Max. width
(maximum
pitch)
Scene
Min. width
(minimum
pitch)
Scene
Menu command Description Setting range Data Refer-
ence
