Omron fq2

External Reference Parameters
FQ2 User’s Manual
467
Appendices
12
126 Mea-
sure-
ment
condi-
tions
Color deviation upper
limit
Setting/Acqui-
sition
0 to 221 221 --- ---
127 Color deviation lower
limit
Setting/Acqui-
sition
0 to 221 0 --- ---
130 Density average upper
limit
Setting/Acqui-
sition
0 to 255 255 --- ---
131 Density average lower
limit
Setting/Acqui-
sition
0 to 255 0 --- ---
132 Density deviation upper
limit
Setting/Acqui-
sition
0 to 127 127 --- ---
133 Density deviation lower
limit
Setting/Acqui-
sition
0 to 127 0 --- ---
134 R average upper limit Setting/Acqui-
sition
0 to 255 255 --- ---
135 R average lower limit Setting/Acqui-
sition
0 to 255 0 --- ---
136 G average upper limit Setting/Acqui-
sition
0 to 255 255 --- ---
137 G average lower limit Setting/Acqui-
sition
0 to 255 0 --- ---
138 B average upper limit Setting/Acqui-
sition
0 to 255 255 --- ---
139 B average lower limit Setting/Acqui-
sition
0 to 255 0 --- ---
310 Logging
condi-
tions
Entire Unit logging
switch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
311 Judgement logging
switch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
312 Average deviation/den-
sity average logging
switch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
313 Color deviation/density
deviation logging switch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
314 R average logging
switch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
315 G average logging
switch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
316 B average logging
switch
Setting/Acqui-
sition
0: Data logging OFF,
1:
Data logg
ing ON
1 --- ---
318 Standard deviation log-
ging switch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
319 Density average differ-
ence logging switch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
320 Density deviation differ-
ence logging switch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
