Omron fq2 User Manual

Menu Tables
412
FQ2 User’s Manual
Inspection
Details
(Shape search II)
Model parameter
Rotation Sets the angle range for the registered
model.
No (default), Yes Scene p. 109
Angle range −180 to 180 Scene p. 109
Model mode You can change to a mode that makes it
easier to search for images similar to a
model.
Fast (default), Stable Scene p. 109
Meas. Parameter
Extraction
condition
Scene p. 108
Candidate
level
Sets the detection target to only objects
with a correlation above the specified
candidate level.
0 to 100 (default: 60) Scene
Extraction
X
Results are output only for objects with a
measured X coordinate that is within this
range.
−999,999,999.9999 to 999,999,999.9999 Scene
Extraction
Y
Results are output only for objects with a
measured Y coordinate that is within this
range.
−999,999,999.9999 to 999,999,999.9999 Scene
Detection
count
Sets the maximum number of detection
results to output.
1 to 32 Scene
Sorting
method
Sets the sort condition to use when mul-
tiple measurement results meet the
extraction conditions..
Corr. ascending order, Corr. descending
order (default), Pos.X ascending order,
Pos.X descending order, Pos.Y ascend-
ing order, Pos.Y descending order
Scene p. 107
Output parameter
Reflect You can specify whether to reflect the
judgement results of an inspection item
in the overall judgement.
No, Yes (default) Scene p. 108
Model parameter
Rotation Sets the angle range for the registered
model.
No (default), Yes Scene p. 116
Angle range −180 to 180 Scene p. 116
Sub-model
number
You can change the number of divisions
of the registered model.
3 × 3, 5 × 5 (default), or 9 × 9 Scene p. 110
Plain inspec-
tion
Enables or disables inspecting plain sec-
tions.
Yes or No (default) Scene p. 110
Meas. Parameter
Sub-pixel You can increase the accuracy of mea-
surement positioning.
No (default), Yes Scene p. 115
Candidate
level
Sets the detection target to only objects
with a correlation above the specified
candidate level.
0 to 100 (default: 60) Scene p. 115
Output parameter
Reflect You can specify whether to reflect the
judgement results of an inspection item
in the overall judgement.
No, Yes (default), Scene p. 115
(Edge widthEdge positionEdge pitch)
Meas. Parameter
Edge level Sets the color density level of the edge. 0 to 100 (default: 50) Scene p. 122,
p. 133,
p. 129
Noise level Sets the color density level to treat as
noise.
0 to 442 (default: 5) Scene p. 123,
p. 133,
p. 129
Output parameter
Reflect You can specify whether to reflect the
judgement results of an inspection item
in the overall judgement.
No, Yes (default), Scene p. 122,
p. 133,
p. 129
Menu command Description Setting range Data Refer-
ence
