Menu Tables
FQ2 User’s Manual
411
Appendices
12
Inspection
Details
(Search)
Model parameter
Rotation Sets the angle range for the registered
model.
No (default), Yes Scene p. 99
Angle range −180 to 180 Scene p. 99
Meas. Parameter
Sub-pixel You can increase the accuracy of mea-
surement positioning.
No (default), Yes Scene p. 97
Meas. Parameter
Extraction
condition
Scene
Candidate
level
Sets the detection target to only objects
with a correlation above the specified
candidate level.
0 to 100 (default: 60) Scene p. 98
Extraction
X
Results are output only for objects with a
measured X coordinate that is within this
range.
−999,999,999.9999 to 999,999,999.9999 Scene
Extraction
Y
Results are output only for objects with a
measured Y coordinate that is within this
range.
−999,999,999.9999 to 999,999,999.9999 Scene
Detection
count
Sets the maximum number of detection
results to output.
1 to 32 Scene
Multi-point
output
Sets whether to output only the result
with the highest correlation, or to output
all results that meet the specified extrac-
tion conditions.
OFF (default) or ON Scene p. 98
Sorting
method
Sets the sort condition to use when mul-
tiple measurement results meet the
extraction conditions.
Corr. ascending order, Corr. descending
order (default), Pos.X ascending order,
Pos.X descending order, Pos.Y ascend-
ing order, Pos.Y descending order
Scene p. 97
Output parameter
Reflect You can specify whether to reflect the
ment results of an inspection item in the
overall judgement.
None, Yes (default) Scene p. 98
Menu command Description Setting range Data Refer-
ence
