Calculations and Judgements Using Inspection Item Data
162
FQ2 User’s Manual
Inspection Item Data That Can Be Used in Expressions
Inspection item Data name Expression text
string
Data range Default
Filter Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−2
Shape Sear. pos.
comp.
Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−2
Scroll X DX −99999.9999 to 99999.9999 0
Scroll Y DY −99999.9999 to 99999.9999 0
Scroll θ DT −180 to 180 0
Position X X −99999.9999 to 99999.9999 0
Position Y Y −99999.9999 to 99999.9999 0
Angle TH −180 to 180 0
Reference X SX −99999.9999 to 99999.9999 0
Reference Y SY −99999.9999 to 99999.9999 0
Reference angle ST −180 to 180 0
Correlation CR 0 to 100 0
Search position
comp.
Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−2
Scroll X DX −99999.9999 to 99999.9999 0
Scroll Y DY −99999.9999 to 99999.9999 0
Position X X −99999.9999 to 99999.9999 0
Position Y Y −99999.9999 to 99999.9999 0
Reference X SX −99999.9999 to 99999.9999 0
Reference Y SY −99999.9999 to 99999.9999 0
Correlation CR 0 to 100 0
Edge position
comp.
Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−2
Scroll X DX −99999.9999 to 99999.9999 0
Scroll Y DY −99999.9999 to 99999.9999 0
Ref. position X X −99999.9999 to 99999.9999 0
Ref. position Y Y −99999.9999 to 99999.9999 0
Reference X SX −99999.9999 to 99999.9999 0
Reference Y SY −99999.9999 to 99999.9999 0
