Calculations and Judgements Using Inspection Item Data
FQ2 User’s Manual
4
Setting Up Inspections
163
2Edge position
comp.
Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−2
Scroll X DX −99999.9999 to 99999.9999 0
Scroll Y DY −99999.9999 to 99999.9999 0
Edge0 position X X0 −99999.9999 to 99999.9999 0
Edge0 position Y Y0 −99999.9999 to 99999.9999 0
Edge1 position X X1 −99999.9999 to 99999.9999 0
Edge1 position Y Y1 −99999.9999 to 99999.9999 0
Edge0 ref. position X
(edge 0 reference posi-
tion X)
SX0 −99999.9999 to 99999.9999 0
Edge0 ref. position Y
(edge 0 reference posi-
tion Y)
SY0 −99999.9999 to 99999.9999 0
Edge1 ref. position X
(edge 1 reference posi-
tion X)
SX1 −99999.9999 to 99999.9999 0
Edge1 ref. position Y
(edge 1 reference posi-
tion Y)
SY1 −99999.9999 to 99999.9999 0
2Edge midpoint
comp.
Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−2
Scroll X DX −99999.9999 to 99999.9999 0
Scroll Y DY −99999.9999 to 99999.9999 0
Edge0 position X X0 −99999.9999 to 99999.9999 0
Edge0 position Y Y0 −99999.9999 to 99999.9999 0
Edge1 position X X1 −99999.9999 to 99999.9999 0
Edge1 position Y Y1 −99999.9999 to 99999.9999 0
Midpoint X MX −99999.9999 to 99999.9999 0
Midpoint Y MY −99999.9999 to 99999.9999 0
Edge0 ref. position X
(edge 0 reference posi-
tion X)
SX0 −99999.9999 to 99999.9999 0
Edge0 ref. position Y
(edge 0 reference posi-
tion Y)
SY0 −99999.9999 to 99999.9999 0
Edge1 ref. position X
(edge 1 reference posi-
tion X)
SX1 −99999.9999 to 99999.9999 0
Edge1 ref. position Y
(edge 1 reference posi-
tion Y)
SY1 −99999.9999 to 99999.9999 0
Ref. midpoint X (refer-
ence midpoint X)
SM
X −99999.
9999 to 99999.9999 0
Ref. midpoint Y (refer-
ence midpoint Y)
SMY −99999.9999 to 99999.9999 0
Inspection item Data name Expression text
string
Data range Default
