Calculations and Judgements Using Inspection Item Data
164
FQ2 User’s Manual
Edge rot. pos.
Comp.
Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−2
Scroll θ DT −180 to 180 0
Edge0 position X X0 −99999.9999 to 99999.9999 0
Edge0 position Y Y0 −99999.9999 to 99999.9999 0
Edge1 position X X1 −99999.9999 to 99999.9999 0
Edge1 position Y Y1 −99999.9999 to 99999.9999 0
Angle TH −180 to 180 0
Edge0 ref. position X
(edge 0 reference. posi-
tion X)
SX0 −99999.9999 to 99999.9999 0
Edge0 ref. position Y
(edge 0 reference. posi-
tion Y)
SY0 −99999.9999 to 99999.9999 0
Edge1 ref. position X
(edge 1 reference. posi-
tion X)
SX1 −99999.9999 to 99999.9999 0
Edge1 ref. position Y
(edge 1 reference. posi-
tion Y)
SY1 −99999.9999 to 99999.9999 0
Reference angle STH −180 to 180 0
Search Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
Correlation CR[0] to CR[31] 0 to 100 0
Position X X[0] to X[31] −99999.9999 to 99999.9999 0
Position Y Y[0] to Y[31] −99999.9999 to 99999.9999 0
Angle TH[0] to TH[31] −180 to 180 0
Reference X SX −99999.9999 to 99999.9999 0
Reference Y SY −99999.9999 to 99999.9999 0
Reference angle ST −180 to 180 0
Detection X RX −99999.9999 to 99999.9999 0
Detection Y RY −99999.9999 to 99999.9999 0
Count C 0 to 32 0
Shape Search II Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15:
Out of range error
−2
Correlation CR 0 to
100 0
Position X X −99999.9999 to 99999.9999 0
Position Y Y −99999.9999 to 99999.9999 0
Angle TH −180 to 180 0
Reference X SX −99999.9999 to 99999.9999 0
Reference Y SY −99999.9999 to 99999.9999 0
Reference angle ST −180 to 180 0
Detection X RX −99999.9999 to 99999.9999 0
Detection Y RY −99999.9999 to 99999.9999 0
Count C 0 to 32 0
Inspection item Data name Expression text
string
Data range Default
