Calculations and Judgements Using Inspection Item Data
FQ2 User’s Manual
4
Setting Up Inspections
165
Sensitive Search Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
Correlation CR 0 to 100 0
Density DV 0 to 221 0
Position X X −99999.9999 to 99999.9999 0
Position Y Y −99999.9999 to 99999.9999 0
Angle TH −180 to 180 0
Detection X RX −99999.9999 to 99999.9999 0
Detection Y RY −99999.9999 to 99999.9999 0
Ref. position X (refer-
ence position X)
SX −99999.9999 to 99999.9999 0
Ref. position Y (refer-
ence position Y)
SY −99999.9999 to 99999.9999 0
Reference angle ST −180 to 180 0
NG sub-region CT 0 to 100 0
Sub-region number AN 1 to 99 0
Sub-region number(X) ANX 0 to 9 0
Sub-region number(Y) ANY 0 to 9 0
Sub-region pos.X (sub-
region position X)
DX −99999.9999 to 99999.9999 0
Sub-region pos.Y (sub-
region position Y)
DY −99999.9999 to 99999.9999 0
Correlation (sub-region) CRN[0] to CRN[80] 0 to 100 0
Deviation (sub-region) DVN[0] to DVN[80] 0 to 221 0
Edge Position Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
Position X X −99999.9999 to 99999.9999 0
Position Y Y −99999.9999 to 99999.9999 0
Ref. position X (refer-
ence position X)
SX −99999.9999 to 99999.9999 0
Ref. position Y (refer-
ence position Y)
SY −99999.9999 to 99999.9999 0
Offset amount DF −99999.9999 to 99999.9999 0
Edge width Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
D. edge width DF 0 to 99999.9999 0
Ref. edge width SW 0 to 99999.9999 0
Edge width W 0 to 99999.9999 0
Inspection item Data name Expression text
string
Data range Default
