Calculations and Judgements Using Inspection Item Data
166
FQ2 User’s Manual
Edge Pitch Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
Edge pitch N 0 to 999 0
Average pitch P 0 to 99999.9999 0
Max. pitch (maximum
pitch)
PH 0 to 99999.9999 0
Min. pitch (minimum
pitch)
PL 0 to 99999.9999 0
Average width W 0 to 99999.9999 0
Max width (maximum
width)
WH 0 to 99999.9999 0
Min width (minimum
width)
WL 0 to 99999.9999 0
Color Data Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
R average AR 0 to 255 0
G average AG 0 to 255 0
B average AB 0 to 255 0
Color diff./dens. Av.
(color difference/density
average)
AD Color difference: 0 to 442
Density average: 0 to 255
0
Clr deviat. (color devia-
tion/density deviation)
DV Color difference: 0 to 221
Density deviation: 0 to 217
0
Area Judgement JG −2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
Area AR 0 to 999999999.9999 0
Gravity X X −99999.9999 to 99999.9999 0
Gravity Y Y −99999.9999 to 99999.9999 0
Reference area SA 0 to 999999999 0
Ref. position X (refer-
ence position X)
SX −99999.9999 to 99999.9999 0
Ref. position Y (refer-
ence position Y)
SY −99999.9999 to 99999.9999 0
Inspection item Data name Expression text
string
Data range Default
