PLC Link Connections
FQ2 User’s Manual
343
Connecting through Ethernet
9
● Get Image Adjustment Data (Command Code: 1010 0040)
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
● Set Image Adjustment Data (Command Code: 1010 0050)
Command (PLC to Vision Sensor)
First word of
command
area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0001 0000 Command code
+3 0000 0000 0100 0000
+4 0000 0000 0000 0000 Position compensation item/filter
item number
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Data number
12-2 External Reference
Parameters p. 430
+7 0000 0000 0000 0000
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0001 0000 Command code
The command code for which the
response applies is stored.
+3 0000 0000 0100 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Acquired data (1,000 times the
value)
+7 0000 0000 0000 0000
First word of
command
area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0001 0000 0001 0000 Command code
+3 0000 0000 0101 0000
+4 0000 0000 0000 0000 Position compensation item/filter
item number
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 Data number
12-2 External Reference
Parameters p. 430
+7 0000 0000 0000 0000
+8 0000 0000 0000 0000 Acquired data (1,000 times the
value)
+9 0000 0000 0000 0000
