Controlling Operation and Outputting Data with TCP No-protocol Communications
368
FQ2 User’s Manual
Data Acquisition/Setting Commands
POSITIONDATA or PD
Get Image Adjustment Data
This command acquires parameters or measurement values from a position compensation item or filter item.
<Command Format>
<Response Format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
Inspection item number Specifies the item number of the position compensation item or of the filter item.
External reference data
number
Specifies the external reference data number.
12-2 External Reference Parameters: p. 430
Acquired value Returns the image adjustment data or threshold value.
12-2 External Reference Parameters: p. 430
PO ON DATA
CR
SI IT
External reference data (4 digits max.)Command
Command
Space
(0x20)
Delimiter
or
DP
CR
External reference data
(4 digits max.)
Delimiter
Space
(0x20)
Item
number
Space
(0x20)
Space
(0x20)
Space
(0x20)
Space
(0x20)
Item
number
CR
Acquired
value
Delimiter
CR
OK
CR
ER
Delimiter
