Menu Tables
428
FQ2 User’s Manual
Run Mode
Menu command Description Setting range Data Refer-
ence
Select display
Graphic Displays the input image. --- --- p. 182
Graphics + Details Displays the inspection item individual
judgement results and measurement val-
ues.
---
Statistical data Displays the total number of measure-
ments and the total number of NG overall
judgements and the NG ratio from when
the power supply was turned ON.
---
All results/Region Displays the inspection item individual
judgement results for all inspection
items.
---
Trend Monitor Displays the individual judgement results
saved in the Sensor in a trend monitor.
--- p. 184
Histogram Displays the individual judgement results
saved in the Sensor in a histogram.
--- p. 185
Model region Changes to Setup Mode and changes
the output form for measurement values.
---
Insp. region Changes to Setup Mode and changes
the parameters for judgement conditions.
---
Adjust judgement
(Except for statistical
data)
Adjusts judgement parameters without
stopping measurements.
--- --- p. 187
Auto display (trend
monitor and histo-
gram only)
Automatically sets the display range
according to the measurement results.
OFF or ON (default) --- p. 184,
p. 185
Display range (trend
monitor and histo-
gram only)
Changes the display range of measure-
ment values.
-999,999,999 to 999,999,999 --- p. 184,
p. 185
Number of data
(trend monitor only)
Changes the number of displayed mea-
surement values.
200, 400, or 1,000 (default: 200) --- p. 184
Number of data (his-
togram only)
Changes the number of displayed mea-
surement values (i.e., the vertical display
range of the histogram).
5 to 1,000 --- p. 185
Clear results
(graphic or graphic +
details list)
Clears the measurement results of the
inspection items.
--- --- ---
Clear results Clears the total results of the inspection
items.
--- --- ---
Delete stats (total
data)
Clears the Statistical data. --- --- ---
Logging
Image logging Starts and stops logging in external
memory.
ON: Start or OFF: Stop --- p. 213
Data logging ON: Start or OFF: Stop ---
TF settings The same as for Setup Mode. (This does not apply to the PC Tool.)
The resolution of the measurement image can be set on the PC Tool.
p. 229
Sensor setting Switches to Setup Mode. --- --- p. 180
Sensor monitor
Multi sensor Simultaneously displays the images for
multiple connected Sensors.
--- --- p. 183
NG sensor From multiple connected Sensors, dis-
plays the image of only the Sensors with
NG results.
--- ---
To Next Page
