Omron fq2 User Manual

External Reference Parameters
FQ2 User’s Manual
447
Appendices
12
310 Logging
condi-
tions
Data logging switch for
entire unit
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
311 Data logging switch for
judgement
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
312 Data logging switch for
scroll X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
313 Data logging switch for
scroll Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
314 Data logging switch
for detected edge posi-
tion X0
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
315 Data logging switch
for detected edge posi-
tion Y0
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
316 Data logging switch
for detected edge posi-
tion X1
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
317 Data logging switch
for detected edge posi-
tion Y1
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
318 Data logging switch
for detected edge mid-
point position X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
319 Data logging switch
for detected edge mid-
point position Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
700 Display
settings
Position compensation
X display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
701 Position compensation
Y display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
702 Detected edge mid-
point position X display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
703 Detected edge mid-
point position Y display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
704 Detected edge position
X0 display
Setting/Acqui-
sition
0:
ON
, 1: OFF 0 --- ---
705 Detected edge position
Y0 display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
706 Detected edge position
X1 display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
707 Detected edge position
Y1 display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
