External Reference Parameters
450
FQ2 User’s Manual
180 Judge-
ment
condi-
tions
Edge position X upper
limit 0
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
181 Edge position X lower
limit 0
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
182 Edge position Y upper
limit 0
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
183 Edge position Y lower
limit 0
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
185 Edge position X upper
limit 1
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
186 Edge position X lower
limit 1
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
187 Edge position Y upper
limit 1
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
188 Edge position Y lower
limit 1
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
190 Edge angle upper limit Setting/Acqui-
sition
−180 to 180 180 --- Adjust judge-
ment
191 Edge angle lower limit Setting/Acqui-
sition
−180 to 180 −180 --- Adjust judge-
ment
192 Theta position compen-
sation upper limit
Setting/Acqui-
sition
−360 to 360 360 --- Adjust judge-
ment
193 Theta position compen-
sation lower limit
Setting/Acqui-
sition
−360
to 360 −360 --- Adjust judge-
ment
310 Logging
condi-
tions
Data logging switch for
entire unit
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
311 Data logging switch for
judgement
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
312
Data logging switch
for position compensa-
tion TH
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
313
Data logging switch
for detected edge posi-
tion X0
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
314
Data logging switch
for detected edge posi-
tion Y0
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
315
Data logging switch
for detected edge posi-
tion X1
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
316
Data logging switch
for detected edge posi-
tion Y1
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
317
Data logging switch
for detected edge angle
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
