External Reference Parameters
FQ2 User’s Manual
463
Appendices
12
120 Mea-
sure-
ment
condi-
tions
Edge color red Setting/Acqui-
sition
0 to 255 255 --- ---
121 Edge color green Setting/Acqui-
sition
0 to 255 255 --- ---
122 Edge color blue Setting/Acqui-
sition
0 to 255 255 --- ---
127 Edge level Setting/Acqui-
sition
0 to 100 50 --- ---
128 Noise level Setting/Acqui-
sition
0 to 442 5 --- ---
130 Judge-
ment
condi-
tions
Edge pitch upper limit Setting/Acqui-
sition
0 to 1,000 1,000 --- Adjust judge-
ment
131 Edge pitch lower limit Setting/Acqui-
sition
0 to 1,000 0 --- Adjust judge-
ment
132 Average pitch upper
limit
Setting/Acqui-
sition
0 to 99,999.9999 99,999.9
999
--- Adjust judge-
ment
133 Average pitch lower
limit
Setting/Acqui-
sition
0 to 99,999.9999 0 --- Adjust judge-
ment
134 Pitch upper limit Setting/Acqui-
sition
0 to 99,999.9999 99,999.9
999
--- Adjust judge-
ment
135 Pitch lower limit Setting/Acqui-
sition
0 to 99,999.9999 0 --- Adjust judge-
ment
136 Average width upper
limit
Setting/Acqui-
sition
0 to 99,999.9999 99,999.9
999
--- Adjust judge-
ment
137 Average width lower
limit
Setting/Acqui-
sition
0 to 99,999.9999 0 --- Adjust judge-
ment
138 Width upper limit Setting/Acqui-
sition
0 to 99,999.9999 99,999.9
999
--- Adjust judge-
ment
139 Width lower limit Setting/Acqui-
sition
0 to 99,999.9999 0 --- Adjust judge-
ment
140 Mea-
sure-
ment
condi-
tions
Edge enhancement
level
Setting/Acqui-
sition
0 to 442 100 --- ---
141 Color to count Setting/Acqui-
sition
(Monochrome Cameras)
0: White, 1: Black
0 --- ---
142 Mode Setting/Acqui-
sition
(Monochrome Cameras)
0: Standard, 1: Precise
0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
