Omron fq2

Specifications and Dimensions
474
FQ2 User’s Manual
Table 1
*1: Tolerance: ±10% max.
*2: Applicable standards: IEC 60825-1:1993 +A1:1997 +A2:2001,
EN 60825-1:1994 +A1:2002 +A2:2001, and JIS C 6802:2005
Table 2
*3: Do not allow the load current to exceed 50 mA. The output circuit may be damaged if the load current exceeds 50 mA.
Materials Sensor: PBT, PC, SUS
Mounting Bracket: PBT
Polarizing Filter Attachment: PBT, PC
Ethernet connector: Oil-resistance vinyl compound
I/O connector: Lead-free heat-resistant PVC
Cover: Zinc-plated steel,
Thickness: 0.6 mm
Case: Aluminum diecast alloy
(ADC-12)
Mounting base: Polycarbon-
ate ABS
Weight Depends on field of view and installation distance. Refer to Table 1. Approx. 160 g without base,
Approx. 185 g with base
Accessories Mounting Bracket (FQ-XL) (1)
Polarizing Filter Attachment (FQ-XF1) (1)
Instruction Manual
Quick Startup Guide
Member Registration Sheet
Warning Label
Mounting Base (FQ-XLC) (1)
Four Mounting Screws (FQ-
XLC) (M3×8 mm)(4)
Instruction Manual
Quick Startup Guide
Member Registration Sheet
LED class
*2
Class 2 ---
Applicable standards EN standard EN 61326 and EC Directive No.2004/104/EC EN 61326-1:2006 and IEC
61010-1
Single-function models Standard models Field of view
(H×V) *1
Installation dis-
tance
Num-
ber of
LEDs
Weight
NPN PNP NPN PNP
FQ2-S10010F FQ2-S15010F FQ2-S20010F FQ2-S25010F 7.5 × 4.7 to
13 × 8.2 mm
38 to 57 mm 4 Approx.
160 g
FQ2-S10050F FQ2-S15050F FQ2-S20050F FQ2-S25050F 13 × 8.2 to
53 × 33 mm
56 to 215 mm 4
FQ2-S10100F FQ2-S15100F FQ2-S20100F FQ2-S25100F 53 × 33 to
240 × 153 mm
220 to 970 mm 8 Approx.
150 g
FQ2-S10100N FQ2-S15100N FQ2-S20100N FQ2-S25100N 29 × 18 to
300 × 191 mm
32 to 380 mm 8
High-resolution models Field of view
(H×V) *1
Installation dis-
tance
Num-
ber of
LEDs
Weight
NPN PNP
FQ2-S30010F-@@@ FQ2-S35010F-@@@ 7.5×6.7 to
13×11.6 mm
38 to 57 mm 4 Approx.
160 g
FQ2-S30050F-@@@ FQ2-S35050F-@@@ 13×11.6 to
53×47.3 mm
56 to 215 mm 4
FQ2-S30100F-@@@ FQ2-S35100F-@@@ 53×47.3 to
240×214 mm
220 to 970 mm 8 Approx.
150 g
FQ2-S30100N-@@@ FQ2-S35100N-@@@ 29×25.9 to
300×268 mm
32 to 380 mm 8
Item NPN PNP
Input specifi-
cations
ON: Shorted to 0 V, or 1.5 V max.
OFF: Open (leakage current: 0.1 mA max.)
ON: Shorted to power supply voltage, or power supply volt-
age −1.5 V max.
OFF: Open (leakage current: 0.1 mA max.)
Output speci-
fications
*3
NPN open collector
30 VDC, 50 mA max., residual voltage: 2.0 V max.
PNP open collector
30 VDC, 50 mA max., residual voltage: 2.0 V max.
Item Single-function
models
Standard mod-
els
High-resolution models
Model NPN FQ2-
S10@@@@
FQ2-
S20@@@@
FQ2-
S30@@@@-08
FQ2-
S30@@@@-08M
FQ2-S30-13 FQ2-S30-
13M
PNP FQ2-
S15@@@@
FQ2-
S25@@@@
FQ2-
S35@@@@-08
FQ2-
S35@@@@-08M
FQ2-S35-13 FQ2-S35-
13M
