Minimum Object Resolution:
• 12 mm minimum object resolution systems:
— With no Floating Blanking: 12.0 mm (0.47 inches)
1
— With 1-beam Floating Blanking: 19 mm (0.75 inches)
1
— With 2-beam Floating Blanking: 26 mm (1.02 inches)
1
• 14 mm minimum object resolution systems:
— With no Floating Blanking: 14.0 mm (0.55 inches)
1
— With 1-beam Floating Blanking: 25 mm (0.98 inches)
1
— With 2-beam Floating Blanking: 36 mm (1.42 inches)
1
• 20 mm minimum object resolution systems:
— With no Floating Blanking: 20.0 mm (0.79 inches)
1
— With 1-beam Floating Blanking: 31 mm (1.22 inches)
1
— With 2-beam Floating Blanking: 42 mm (1.65 inches)
1
• 30 mm minimum object resolution systems:
— With no Floating Blanking: 30.0 mm (1.18 inches)
1
— With 1-beam Floating Blanking: 52 mm (2.05 inches)
1
— With 2-beam Floating Blanking: 74 mm (2.91 inches)
1
1
Use of Exact Channel will increase this value
Floating Blanking
OFF
Floating Blanking
1 Channel
Floating Blanking
2 Channels
MCJ-12 25 mm 31 mm 37 mm
MCJ-20 29 mm 40 mm 50 mm
MCJ-30 32 mm 52 mm 73 mm
MCJ4700 Joint Resolution (Resolution at the corner)
Safety Output: Din & Solid State Output ve
rsion of Metal Chassis Controllers: Two PNP each output
sourcing 625 mA @ 24 VDC.
Relay version of metal chassis controller only: 1 N.O. and 1 N.C. /N.O. rated for 6A at 230 VAC.
Auxiliary (non-safety) Output:
Din & Solid State Output version of Metal Chassis Controllers: One NPN output sinking 100 mA @
24 VDC. One PNP
sourcing 250 mA @ 24 V
DC.
Relay version of metal chassis controller only: 1 N.O./N.C. rated at 3A @ 230 VAC.
MPCE: 50mA
@ 24 VDC
Maximum Res
ponse Time: <See Tab le 14 -1 , Table 14-2 or Ta ble 1 4-3 for details of response time by
protected height.
Power Input:
Din & Solid State Output version of Metal Chassis Controllers: 24 V
DC ± 20%, 2A*, . Power
supply must meet the requirements of IEC 60204-1 and IEC 61496-1. OMRON STI part number
42992 or equivalent.
