Section 2 NS Series Functions 2-8 Common Functional Object Functions
2-106
NS Series Programming Manual
Password Tab Page in Password
Setting Dialog Box
Passwords and
keyboard screens are
set for levels 1 and 5.
The password function
with levels is enabled
and the authentication
screen is specified for
display after
authentication is
canceled.
Model Selection Tab Page in
Password Setting Dialog Box
The passwords for
levels 1 and 5 are set
for command buttons
to change the screen.
A
uthentication screen
Operator
Manager
Level 1 password input,
authenticating level 1
Operator screen
Level 5 password input,
authenticating level 5
Manager screen
Cancel
authentication.
Cancel
authentication.
Command button to
cancel authentication
Command button to
cancel authentication
