Section 2 NS Series Functions 2-17 Data Blocks
2-400
NS Series Programming Manual
2-17-3 Using Data Blocks
This section explains how to use a data block table.
Using Data Block Tables
Selecting a Record on a Data Block Table
Click the record number to select record from the data block table. The record numbers are automati-
cally displayed in the data block table.
The selected record is displayed in reverse video and “*” is added to the record number.
Record numbers are automatically displayed.
Inputting Value in a Data Block Table
The user can change the value of a field in the data block table.
Touch field for which you want to change the value. The keyboard or keypad will be displayed. Then,
change the value.
To Next Page
