Appendices Appendix-4 Addresses for Functional Objects
A-22
NS Series Programming Manual
A-4-2 Using Tags
The data types for tags that can be set for functional objects (including arrays) are shown in the
following table.
B (bit):
BOOL
W (1 word):
CHANNEL, INT, UINT, UINT_BCD, WORD
D (2 words) h:
DINT, UDINT, REAL, UDINT_BCD, DWORD
S (text string):
STRING
Functional
object
Tab page name Set address B W D S
General Write address OK No No No
Display address 1 OK No No No
ON/OFF
Buttons
Display address 2 OK No No No
Color/Shape Color 1 (OFF color) No OK No No
Color 2 (ON color) No OK No No
Color 3 No OK No No
Color 4 No OK No No
Label Switch label specification OK No No No
Indirect specification of label character color No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Flicker Flicker specification OK No No No
Control Flag Input enabled/disabled flags OK No No No
Display/no display flags OK No No No
General Write address No OK
(See
note 1.)
OK
(See
note 1.)
No Word Buttons
Indirect write value specification No OK
(See
note 1.)
OK
(See
note 1.)
No
Indirect increment/decrement specification No OK
(See
note 1.)
OK
(See
note 1.)
No
Color/Shape Indirect specification of normal background color No OK No No
Indirect specification of background color when
object is pressed
No OK No No
Label Indirect specification of label character color No OK No No
Frame Indirect specification of frame ON/OFF OK No No No
Indirect specification of upper limit No OK
(See
note 1.)
OK
(See
note 1.)
No
Upper/lower
Limits
Indirect specification of lower limit No OK
(See
note 1.)
OK
(See
note 1.)
No
Flicker Flicker specification OK No No No
Write Settings Write notification address OK No No No
Control Flag Input enabled/disabled flags OK No No No
Display/no display flags OK No No No
General Indirect specification of screen switch page No OK No No Command
Buttons
Switch screen page notification address No OK No No
String source address No OK
(See
note 2.)
No OK
Indirect specification of data block number No OK No No
Indirect specification of the record number No OK No No
Specification of address when the final record is
read
OK No No No
