Appendices Appendix-4 Addresses for Functional Objects
A-16
NS Series Programming Manual
Appendix-4 Addresses for Functional Objects
A-4-1 Using Direct Addresses
The following table shows the types of addresses that can be set for functional objects.
B: Bit
W: Word
L: 32-bit data
If data is written to a bit for an address for which only W or L can be set, all other bits will be set to 0.
Refer to Appendix 3 for information on the PLC addresses that can be used.
Functional
object
Tab page name Set address B W L
General Write address OK No No
Display address 1 OK No No
ON/OFF
Buttons
Display address 2 OK No No
Color/Shape Color 1 (OFF color) (See note.) No OK No
Color 2 (ON color) (See note.) No OK No
Color 3 No OK No
Color 4 No OK No
Label Switch label specification OK No No
Indirect specification of label character color No OK No
Frame Indirect specification of frame ON/OFF OK No No
Flicker Flicker specification OK No No
Control Flag Input enabled/disabled flags OK No No
Display/no display flags OK No No
General Write address No OK OK Word Buttons
Indirect write value specification No OK OK
Indirect increment/decrement specification No OK OK
Color/Shape Indirect specification of normal background color No OK No
Indirect specification of background color when object is
pressed
No OK No
Label Indirect specification of label character color No OK No
Frame Indirect specification of frame ON/OFF OK No No
Indirect specification of upper limit No OK OK
Upper/lower Limits
Indirect specification of lower limit No OK OK
Flicker Flicker specification OK No No
Write Settings Write notification address OK No No
Control Flag Input enabled/disabled flags OK No No
Display/no display flags OK No No
General Indirect specification of screen switch page No OK No Command
Buttons
Switch screen page notification address No OK No
String source address No OK No
Color/Shape Indirect background color specification No OK No
Label Indirect specification of label character color No OK No
Flicker Flicker specification OK No No
Control Flag Input enabled/disabled flags OK No No
Display/no display flags OK No No
Note: The address name in parentheses ( ) is the name when Rectangle Simple (Type 1), Rectangle Simple (Type 2-1),
Rectangle Simple (Type 2-2), Circle Simple (Type 1), Circle Simple (Type 2-1), or Circle Simple (Type 2-2) are
selected as the button type.
