Appendices Appendix-4 Addresses for Functional Objects
A-17
NS Series Programming Manual
Functional
object
Tab page name Set address B W L
Bit lamps General Display address OK No No
Color/Shape Indirect specification of background color when ON No OK No
Indirect specification of background color when OFF No OK No
Label Indirect specification of label character color No OK No
Flicker Flicker specification OK No No
Control Flag Display/no display flags OK No No
Word lamps General Display address No OK No
Color/Shape Indirect specification of background color when 0 No OK No
Indirect specification of background color when 1 No OK No
Indirect specification of background color when 2 No OK No
Indirect specification of background color when 3 No OK No
Indirect specification of background color when 4 No OK No
Indirect specification of background color when 5 No OK No
Indirect specification of background color when 6 No OK No
Indirect specification of background color when 7 No OK No
Indirect specification of background color when 8 No OK No
Indirect specification of background color when 9 No OK No
Label Indirect specification of label character color No OK No
Flicker Flicker specification OK No No
Control Flag Display/no display flags OK No No
Text objects Background Indirect background color specification No OK No
Indirect specification of label character color No OK No
Indirect specification of label string file line No OK No
Label
Indirect reference to string number No OK No
Message Address for switching status No OK No
Frame Indirect specification of frame ON/OFF OK No No
Flicker Flicker specification OK No No
Control Flag Display/no display flags OK No No
Communications address No OK OK General
Indirect specification of units/scale number No OK No
Numeral display
& input objects
Text Attributes Indirect specification of numeral/character color No OK No
Background Indirect background color specification No OK No
Frame Indirect specification of frame ON/OFF OK No No
Indirect specification of input upper limit No OK OK
Input Upper and
Lower Limits
Indirect specification of input lower limit No OK OK
Limit Monitor Indirect specification of upper limit monitoring No OK OK
Indirect specification of lower limit monitoring No OK OK
Flicker Flicker specification OK No No
Write Settings Write notification address OK No No
Control Flag Input enabled/disabled flags OK No No
Display/no display flags (all) OK No No
Display/no display flags (numerals) OK No No
General String start address No OK No
Text Attributes Indirect character color specification No OK No
String
display & input
objects
Background Indirect background color specification No OK No
Frame Indirect specification of frame ON/OFF OK No No
Flicker Flicker specification OK No No
To Next Page
