Appendices Appendix-4 Addresses for Functional Objects
A-18
NS Series Programming Manual
Functional
object
Tab page name Set address B W L
Write Settings Write notification address OK No No
Input enabled/disabled flags OK No No
String display &
input objects
Control Flag
Display/no display flags OK No No
List data address No OK No General
Indirect file line specification No OK No
Background Indirect background color specification No OK No
Selection line number address No OK No Selection
Operation
Selection line string address No OK No
Frame Indirect specification of frame ON/OFF OK No No
Flicker Flicker specification OK No No
Input enabled/disabled flags OK No No Control Flag
Display/no display flags OK No No
Display block number specification address No OK No
Address specifying display start line No OK No
List selection
objects
External Control
List re-display specification OK No No
General Communications address No OK OK
Text Attributes Indirect specification of numeral/character color No OK No
Background Indirect background color specification No OK No
Indirect specification of input upper limit No OK OK Upper/lower Limits
Indirect specification of input lower limit No OK OK
Flicker Flicker specification OK No No
Write Settings Write notification address OK No No
Input enabled/disabled flags OK No No
Thumbwheel
switches
Control Flag
Display/no display flags OK No No
General Communications address No OK OK
Indirect specification of border value (maximum) No OK OK
Indirect specification of border value (delimiter 1) No OK OK
Indirect specification of border value (delimiter 2) No OK OK
Border
Indirect specification of border value (minimum) No OK OK
Indirect specification of range 1 color No OK No
Indirect specification of range 2 color No OK No
Color
Indirect specification of range 3 color No OK No
Indirect background color specification No OK No
Indirect specification of range 1 background color No OK No
Indirect specification of range 2 background color No OK No
Background
Indirect specification of range 3 background color No OK No
Flicker Flicker specification OK No No
Analog
meters
Control Flag Display/no display flags OK No No
General Communications address No OK OK
Indirect specification of border value (maximum) No OK OK
Indirect specification of border value (delimiter 1) No OK OK
Indirect specification of border value (delimiter 2) No OK OK
Border
Indirect specification of border value (minimum) No OK OK
Indirect specification of range 1 color No OK No
Indirect specification of range 2 color No OK No
Level meters
Color
Indirect specification of range 3 color No OK No
