Appendices Appendix-4 Addresses for Functional Objects
A-19
NS Series Programming Manual
Functional
object
Tab page name Set address B W L
Frame Indirect specification of frame ON/OFF OK No No
Background Indirect background color specification No OK No
Level display
objects
Indirect specification of range 1 background color No OK No
Indirect specification of range 2 background color No OK No
Indirect specification of range 3 background color No OK No
Flicker Flicker specification OK No No
Control Flag Display/no display flags OK No No
General Display refresh bit OK No No Broken-line
Graphs
No. of display-enabled points No OK No
Indirect specification of scale line display/hide setting OK No No
Graph data OK OK OK
Indirect specification of number of graph points No OK No
Indirect specification of display start position No OK No
Indirect specification of maximum graph data value OK OK OK
Graph
Indirect specification of minimum graph data value OK OK OK
Background Indirect background color specification No OK No
Flicker Flicker specification OK No No
Control Flag Input enabled/disabled flags OK No No
Display/no display flags OK No No
Bitmaps General Address for indirect specification of display file No OK No
Frame Indirect specification of frame ON/OFF OK No No
Flicker Flicker specification OK No No
Control Flag Display/no display flags OK No No
Alarm/event data OK No No General
Alarm and event information OK OK No
Alarm/event
display
objects
Flowing Text Specification of flowing text display start OK No No
Background Indirect background color specification No OK No
Frame Indirect specification of frame ON/OFF OK No No
Flicker Flicker specification OK No No
Input enabled/disabled flags OK No No
Control Flag
Display/no display flags OK No No
Selected alarm ID write address No OK No
Alarm/event data OK No No
General
Alarm information OK OK No
Alarm/event
summary and
history objects
Background Indirect background color specification No OK No
Frame Indirect specification of frame ON/OFF OK No No
Flicker Flicker specification OK No No
Control Flag Input enabled/disabled flags OK No No
Display/no display flags OK No No
Date objects Background Indirect background color specification No OK No
Frame Indirect specification of frame ON/OFF OK No No
Flicker Flicker specification OK No No
Control Flag Input enabled/disabled flags OK No No
Display/no display flags OK No No
Background Indirect background color specification No OK No
Frame Indirect specification of frame ON/OFF OK No No
Flicker Flicker specification OK No No
Input enabled/disabled flags OK No No
Time objects
Control Flag
Display/no display flags OK No No
