Omron NS10-TV Series

Appendices Appendix-4 Addresses for Functional Objects
A-20
NS Series Programming Manual
Functional
object
Tab page name Set address B W L
Graph data OK OK OK
Indirect specification of maximum graph data value OK OK OK
General
Indirect specification of minimum graph data value OK OK OK
Indirect specification of time axis No OK No
Time axis data destination No OK No
Time axis data enable/disable bit OK No No
Display refresh notification OK No No
Scroll seconds specification No OK No
Display
Time data transmission destination No OK No
Background Indirect background color specification No OK No
Flicker Flicker specification OK No No
Input enabled/disabled flags OK No No
Data log graphs
Control Flag
Display/no display flags OK No No
General Frame page number No OK No
Input enabled/disabled flags OK No No
Frame
objects
Control Flag
Display/no display flags OK No No
Specify interlock (Data Prohibition Flag) OK No No
Indirect reference of maximum limit for numeral field No OK OK
Indirect reference of minimum limit for numeral field No OK OK
Address for numeral field No OK OK
General
Address for string field No OK OK
Text Attribute Indirect specification of text colors No OK No
Write Setting Write notification address OK No No
Input enable/disable flag OK No No
Data block
tables
Control Flag
Display enable/disable flag OK No No
Indirect specification of color
No OK No
Indirect specification of the number of vertices
No OK No
Consecutive
Line Drawing
General
Starting address of the X-Y coordinates data
No OK No
Input
OK No No
Perform an action when a value changed
OK OK No
Write bit
OK No No
Write word
No OK OK
Write string
No OK No
Switch screen
No OK No
Key Buttons
No OK No
Data Block Control
No OK No
Contents Control
No OK No
General
Macro
OK OK OK
Display Address 1
OK OK OK
Display Address 2
OK No No
Indirect Reference for Color
No OK No
Color/Shape
Display/hide
OK No No
Switch labels
OK OK No
Label
Indirect Reference for Text Color
No OK No
Multifunction
Object
Flicker
Flicker specification
OK No No
Frame Indirect reference for frame ON/OFF.
OK No No
Flicker Flicker specification
OK No No
Contents
Display
Control Flag Display/hide flag
OK No No
