Section 2 NS Series Functions 2-10 Lamps
2-160
NS Series Programming Manual
Frame Tab Page
Specify the colors and sizes of the lamp frame to change the shape or color when the button is de-
pressed or raised. Refer to Frames under 2-8 Common Functional Object Functions for details.
Flicker Tab Page
Make flicker settings to make the lamp flicker (flash). Refer to Flicker under 2-8 Common Functional
Object Functions for details.
Control Flag Tab Page
Control flags control the display of functional objects. Use control flags to enable display when the
contents of an address turn ON or OFF. Refer to Control Flags under 2-8 Common Functional Object
Functions for details.
Macro Tab Page
Macros can be specified for word lamps.
Macros executed by the following trigger can be registered.
Trigger Details
When changing value Executes macro when the contents of the address change.
Refer to NS-series Macro Reference on the CX-Designer for information on setting macros.
Size/Position Tab Page
Displays and sets the functional object size and position. Refer to Size/Position under 2-8 Common
Functional Object Functions for details.
