Section 2 NS Series Functions 2-12 Display and Input Objects
2-269
NS Series Programming Manual
4. Double-click the objects to display the Properties Dialog Box. Select Show the maximum value and
Show the minimum value under Function on the General Tab Page.
5. Use a Command Button to create a keypad. Refer to Key Buttons under 2-9-3 Command Buttons
for details on how to create keypad command buttons. Set the destination to the Input Field with
Focus option under the properties settings for each Command Button.
6. Check the keypad operation using the test function.
When the focus is on the numeral display and input object, the input value is displayed in the tempo-
rary input object. Click the Command Button to overwrite the present values with the new input value.
