Section 2 NS Series Functions 2-13 Display
2-295
NS Series Programming Manual
Frame Tab Page
Select a frame color.
1
No. Item Contents
1 Frame If you specify a frame, then select a frame color.
N
N
N
o
o
o
t
t
t
e
e
e
♦
A frame cannot be set when using a 800x600 size.
Size/Position Tab Page (Extension Tab)
Specify the display position for the video display by entering the horizontal position (X) and the vertical
position (Y) from the upper left corner of the screen. The setting ranges for X and Y are 0 to 160 and 0
to 120. Specify vertical and horizontal position in dot units.
1
No. Item Details
1. Position from the
upper left of the
screen
Specify the display position from the upper left corner of the screen. Setting ranges are as
follows:
X:0 to 160
Y:0 to 120
N
N
N
o
o
o
t
t
t
e
e
e
♦
The video display cannot be moved outside of the screen.
♦
The position can be set only when choosing 640x480 or 320x240 size on the NS12.
To Next Page
