Section 2 NS Series Functions 2-17 Data Blocks
2-386
NS Series Programming Manual
String Data
When selecting string data for the data format, set the following items.
Select
String
.
String: Sets the display format.
Keypad: Sets the input method, and the display position and size of the keypad.
The detailed settings for each tab page are the same as for Numeral Display & Input objects. Refer to
2-12 Display and Input Objects for details.
N
N
N
o
o
o
t
t
t
e
e
e
♦
The item Other Input Method (command button etc.) does not appear on the Keypad Tab Page
of the Field Setting Dialog Box for Data Block Tables.
Record Label Setting
No. Item Details
1 String Length Sets the number of valid characters for record labels (1 to 32).
2 Storage String
Type
Selects one of the following as the storage type for record labels in
PT memory.
ASCII code
Unicode
To Next Page
