Section 2 NS Series Functions 2-20 Special Functions
2-464
NS Series Programming Manual
1
2
3
4
5
No. Setting Details
1 Host name
Press
Host name to display the Host Selection Dialog Box and select the Host. Host
names set using CX-Designer can be selected.
2 Mode
Press
Mode to display the Mode Change Dialog Box. Switches to the specified PLC
mode.
3 Type
Press
type to display the CH Type Selection Dialog Box. Sets the word type to be
monitored.
4 JUMP
Press
JUMP to display the JUMP Dialog Box. Sets the addresses to be monitored.
Press the
Set Button in the JUMP Dialog Box to the following number of words starting
from the specified address.
NS15: 150 words
NS12: 100 words
NS10/NS8: 50 words
NS5: 25 words
5
▲/▼
(Previous/
next)
Press the
Up Button or Down Button to scroll the addresses being displayed by one
page. You cannot scroll beyond the upper and lower limits of the addresses.
