Appendices Appendix-1 Specifications
A-4
NS Series Programming Manual
Item Specification
User screens
• Up to 4,000 screens, including base and pop-up screens, can be created per
project.
• Up to 3 pop-up screens can be overlapped.
Sheets • Up to 32 sheets can be created per project.
• Up to 10 sheets can be set for layered display on standard screens.
• Up to 1,024 functional objects, including those inside frames and tables, can be
created per sheet. Up to 2,048 graphic displays can be created per sheet.
No. of label switches • Up to 16.
Background screen
files
• Displayable file formats
BMP, JPEG (RLE-format bmp files and progressive jpeg are not supported.)
Background colors 256
Project registration
method
Transfer from CX-Designer Data transfer (under File/Data transfer) to PT.
• PT - Transfer - Transfer [To PT]
• PT - Transfer - Quick Transfer [To PT]
• PT - Transfer - Transfer Program
N
N
N
o
o
o
t
t
t
e
e
e
♦
With project data versions lower than 8.0, a maximum total of 1,024 objects (including functional
objects, frames, tables, and graphic displays) can be created per screen.
