Appendices Appendix-5 Controller Link Network Status Read List
A-30
NS Series Programming Manual
First read address (n) Bits Status Details
0 to 7 Node 1 n+7
8 to 15 Node 2
0 to 7 Node 3 n+8
8 to 15 Node 4
0 to 7 Node 5 n+9
8 to 15 Node 6
0 to 7 Node 7 n+10
8 to 15 Node 8
0 to 7 Node 9 n+11
8 to 15 Node 10
0 to 7 Node 11 n+12
8 to 15 Node 12
0 to 7 Node 13 n+13
8 to 15 Node 14
0 to 7 Node 15 n+14
8 to 15 Node 16
0 to 7 Node 17 n+15
8 to 15 Node 18
0 to 7 Node 19 n+16
8 to 15 Node 20
0 to 7 Node 21 n+17
8 to 15 Node 22
0 to 7 Node 23 n+18
8 to 15 Node 24
0 to 7 Node 25 n+19
8 to 15 Node 26
0 to 7 Node 27 n+20
8 to 15 Node 28
0 to 7 Node 29 n+21
8 to 15 Node 30
0 to 7 Node 31 n+22
8 to 15
Data Link Status
Node 32
0 Node 1
1 Node 2
2 Node 3
3 Node 4
4 Node 5
5 Node 6
6 Node 7
7 Node 8
8 Node 9
9 Node 10
10 Node 11
11 Node 12
12 Node 13
13 Node 14
14 Node 15
n+23
15 Node 16
0 Node 17
1 Node 18
2 Node 19
3 Node 20
4 Node 21
5 Node 22
6 Node 23
n+24
7
Data Link Normal Operation
Status
Node 24
