4-6
L3-02
Stall prevention
selection during
acceleration
Sets the stall prevention level (current
limit) during acceleration as a percentage
of the Inverter rated current.
0 to 200% 120% 6-17
L3-04
Stall prevention
selection during
deceleration
If using the dynamic brake option (Brak-
ing Resistor Units and Braking Units), be
sure to set parameter L3-04 to 0 (dis-
abled).
0 to 2 1 6-19
*1. Values for 200 V class Inverters are shown. For a 400 V class Inverter the values have to be doubled.
*2. The setting range is 10% to 200% of the Inverter rated output current. The value for a 200 V class Inverter of 0.4 kW is given.
*3. The factory setting depends on the Inverter capacity. The value for a 200 V class Inverter of 0.4 kW is given
Table 4.1 Basic Parameter Settings
: Must be set. : Set as required.
Class
Parameter
Number
Name Description
Setting
Range
Factory
Setting
Page
