Protective and Diagnostic Functions
7-11
îš‹ Operator Programming Errors
An Operator Programming Error (OPE) occurs when an inapplicable parameter is set or an individual param-
eter setting is inappropriate. The Inverter will not operate until the parameter is set correctly; however, no
alarm or fault outputs will occur. If an OPE occurs, change the appropriate parameter by checking the cause
shown in Table 7.3. When OPE error is displayed, press the ENTER key to display U1-34 (OPE Detected).
This monitor will display the parameter that is causing the OPE error.
Table 7.3 Operator Programming Errors
Display Meaning Probable Causes Corrective Action
Inverter kVA Setting Error
The control board was replaced and
the kVA parameter (o2-04) is set
incorrectly
Enter the correct kVA
setting (o2-04) by refer-
ring to the table “Factory
settings that change with
the Inverter kVA set-
ting“on page 5-60.
OPE01
kVA Selection
Parameter Setting Out of Range
Parameter setting was outside of the
allowed range.
Verify the parameter set-
tings.
OPE02
Limit
Multi-function Input
Selection Error
One of the following errors has been
made in the multi-function input (H1-
01 to H1-05) settings:
• Duplicate functions were selected.
• UP/DOWN command (setting 10
and 11) were not set simulta-
neously.
• The UP/DOWN commands (10
and 11) and Accel/decel ramp hold
(A) were set at the same time.
• More than one of the Speed Search
inputs (61, 62, 64) were set simoul-
taneosly.
• External Baseblock NO (8) and
External Baseblock NC (9) were
set at the same time.
• The UP/DOWN commands (10
and 11) were selected while PI
Control (b5-01) was enabled.
• The Emergency Stop Command
NO and NC were set at the same
time.
• Motor Preheat (60) and Motor Pre-
heat 2 (80) were set simulta-
neously.
• Emergency Override FWD (81)
and Emergency Override REV (82)
are set simultaneously.
Verify the parameter set-
tings in H1-
OPE03
Terminal
RUN/Reference Command
Selection Error
The Reference Source Selection
b1-01 and/or the RUN Source
Selection parameter b1-02 are set
to 3 (option board) but no option
board is installed.
Option board is not installed or is
installed incorrectly
• Verify that the board is
installed. Switch off
the power supply and
re-install the option
board.
• Recheck the setting of
b1-01 and b1-02.
OPE05
Sequence Select
