5-18
îš‹ Reference Parameters: d
îš„Preset Reference: d1
Note:The unit is set in o1-03 (frequency units of reference setting and monitor, default: 0.01 Hz).
îš„Reference Limits: d2
Note:The PI Sleep Function is also available and can be used without enabled PI controller. It can be used to let the inverter switch off automatically when a
minimum output frequency (set in b5-15) has been output for a time longer than b5-16. Refer also to page page 6-94, PI Sleep Function.
Param-
eter
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
d1-01
Frequency
reference 1
Sets the frequency reference.
0 to
FMAX
0.00
Hz
Yes A 280H 6-7
d1-02
Frequency
reference 2
Sets the frequency reference when
multi-step speed command 1 is ON
for a multi-function input.
0.00
Hz
Yes A 281H 6-7
d1-03
Frequency
reference 3
Sets the frequency reference when
multi-step speed command 2 is ON
for a multi-function input.
0.00
Hz
Yes A 282H 6-7
d1-04
Frequency
reference 4
Sets the frequency reference when
multi-step speed commands 1 and
2 are ON for multi-function inputs.
0.00
Hz
Yes A 283H 6-7
d1-17
Jog frequency
reference
Sets the frequency reference when
the jog frequency reference selec-
tion, FJOG command, or RJOG
command is ON.
6.00
Hz
Yes A 292H
6-7
6-62
Param-
eter
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
d2-01
Frequency refer-
ence upper limit
Sets the frequency reference upper
limit as a percentage of the max.
output frequency.
0.0 to
110.0
100.0% No Q 289H
6-24
6-55
d2-02
Frequency refer-
ence lower limit
Sets the frequency reference lower
limit as a percentage of the maxi-
mum output frequency.
0.0 to
110.0
0.0% No Q 28AH
6-24
6-55
d2-03
Master speed ref-
erence lower
limit
Sets the master speed reference
lower limit as a percentage of the
max. output frequency.
0.0 to
110.0
0.0% No A 293H
6-24
6-55
