User Parameter Tables
5-19
Jump Frequencies: d3
Reference Frequency Hold: d4
Param-
eter
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
d3-01 Jump frequency 1
Sets the jump (resonance) frequen-
cies in Hz.
The function is disabled when the
jump frequency is set to 0 Hz.
Always ensure the following set-
ting order:
d3-01 ≥ d3-02 ≥ d3-03
Operation in the jump frequency
range is prohibited but during
acceleration and deceleration, the
speed changes smoothly without
jumping over the set frequencies
0.0 to
200.0
0.0 Hz No A 294H 6-23
d3-02 Jump frequency 2 0.0 Hz No A 295H 6-23
d3-03 Jump frequency 3 0.0 Hz No A 296H 6-23
d3-04
Jump frequency
width
Sets the jump frequency bandwidth
in Hz.
The jump frequency range will be
the jump frequency ± d3-04.
0.0 to
20.0
1.0 Hz No A 297H 6-23
Param-
eter
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
d4-01
Frequency refer-
ence hold func-
tion selection
Sets whether or not frequency ref-
erence value on hold will be
recorded.
0: Disabled (when operation is
stopped or the power is turned
on again the frequency refe-
rence is set to 0.)
1: Enabled (when operation is
stopped or the power is turned
on again the inverter starts at
the previous hold frequency.)
This function is available when the
multi-function inputs “Accel/Decel
Ramp Hold” or “UP/DOWN”
commands are set.
0 or 1 0 No A 298H
6-54
6-55
d4-02
Trim Control
Level
Sets the frequency to be added to
or subtracted from the analog fre-
quency reference as a percentage
of the max. output frequency.
Enabled when the Trim control
increase command or Trim control
decrease command is set for a
multi-function input.
0 to
100
10% No A 299H 6-58
