User Parameter Tables
5-23
îš‹ Terminal Function Parameters: H
îš„Multi-function Digital Inputs: H1
Multi-function Digital Input Functions
Param-
eter
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
H1-01
Terminal S3
function selection
Multi-function digital input 1 0 to 82 24 No A 400H –
H1-02
Terminal S4
function selection
Multi-function digital input 2 0 to 82 14 No A 401H –
H1-03
Terminal S5
function selection
Multi-function digital input 3 0 to 82
3 (0)
*1
*1. The values in parentheses indicate initial values when initialized in 3-wire-sequence.
No A 402H –
H1-04
Terminal S6
function selection
Multi-function digital input 4 0 to 82
4 (3)
*1
No A 403H –
H1-05
Terminal S7
function selection
Multi-function digital input 5 0 to 82
6 (4)
*1
No A 404H –
Setting
Value
Function Page
0 3-wire sequence (Forward/Reverse Run command) 6-10
1 Local/Remote selection (ON: Operator, OFF: Parameter b1-01/b1-02 setting) 6-52
2 Operation Source Option Card/Inverter selection (ON: Parameter b1-01/b1-02 setting) 6-60
3
Multi-step speed reference 1
When H3-09 is set to 2, this function is combined with the master/auxiliary speed switch.
6-7
4 Multi-step speed reference 2 6-7
6 Jog frequency command (higher priority than multi-step speed reference) 6-7
7 Acceleration/Deceleration time selection 1 6-15
8 External baseblock NO (NO contact: Baseblock at ON) 6-53
9 External baseblock NC (NC contact: Baseblock at OFF) 6-53
A Acceleration/deceleration ramp hold (ON: Acceleration/deceleration stopped, frequency is hold) 6-54
C Multi-function analog input A2 enable (ON: Enable) 6-53
F Terminal not used –
10 UP command (Always set with the DOWN command) 6-55
11 DOWN command (Always set with the UP command) 6-55
12 FJOG command (ON: Forward run at jog frequency d1-17) 6-62
13 RJOG command (ON: Reverse run at jog frequency d1-17) 6-62
14 Fault reset (Reset when turned ON) 7-2
15 Emergency stop (NO: Deceleration to stop with deceleration time set in C1-09 when ON.) 6-14
17 Emergency stop (NC: Deceleration to stop with deceleration time set in C1-09 when OFF) 6-14
18
Timer function input
(times are set in b4-01 and b4-02 and the timer function outputs are set in H2-.)
6-86
19 PI control disable (ON: PI control disabled) 6-87
1B
Parameters write enable
(ON: All parameters can be set. OFF: All parameters are write protected.)
6-117
1C Trim control increase (ON: d4-02 frequency is added to analog frequency reference.) 6-58
1D Trim control decrease (ON: d4-02 frequency is subtracted from analog frequency reference.) 6-58
1E Analog frequency reference sample/hold (ON: reference is sampled and hold) 6-59
