* This setting is effective only, if the HOA operator JVOP-162 is used.
 Multi-function Digital Outputs: H2
Multi-function Digital Output Functions
20 to 2F
External fault
Input mode: NO contact/NC contact, detection mode: normal/during operation
6-63
30
PI control integral reset
(ON: integral reset and hold as long as input is ON)
6-87
31 PI control integral hold (ON: integral is hold) 6-87
34 PI soft starter disable (ON: disabled) 6-87
35 PI input characteristics switch 6-87
36 Operation Source Option/Inverter selection 2 (ON: option card) 6-60
60 Motor preheat command 1 (ON: Performs motor preheat) 6-106
61 External speed search command 1 (ON: Speed search from maximum output frequency) 6-39
62 External speed search command 2 (ON: Speed search from set frequency) 6-39
64 External speed search command 3 6-39
67 Communications test mode 6-85
68 High Slip braking (HSB) 6-109
69 Jog Frequency 2 6-7
6A Drive enable (ON: Drive enabled) 6-54
6B Operation Source Communication/Inverter selection (ON: RS-422/485 port) 6-60
6C Operation Source Communication/Inverter selection 2 (ON: inverter settings) 6-60
6D* AUTO mode selection (ON: AUTO mode active) 6-61
6E* HAND mode selection (ON: HAND mode active) 6-61
70 Bypass Drive Enable (ON: Inverter enabled) 6-54
80 Motor Preheat 2 (ON: motor performs preheat 2) 6-106
81 Emergency Override Forward (ON: Inverter performs emergency override in forward direction) 6-108
82 Emergency Override Reverse (ON: Inverter performs emergency override in reverse direction) 6-108
Param-
eter
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
H2-01
Terminal M1-M2
function selection
Multi-function digital
output 1
0 to 3D 0 No A 40BH –
H2-02
Terminal M3-M4
function selection
Multi-function digital
output 2
0 to 3D 1 No A 40CH –
Setting
Value
Function Page
0 During run 1 (ON: run command is ON or voltage is being output) 6-64
1 Zero speed 6-65
2
f
ref
/f
out
agree 1 (detection width L4-02 is used.)
6-25
3
f
ref
/f
set
agree 1
(ON: Output frequency = ±L4-01, with detection width L4-02 used and during frequency agree)
6-25
4
Frequency detection 1
(ON: +L4-01 ≥ output frequency ≥ -L4-01, detection width L4-02 used)
6-25
5
Frequency detection 2
(ON: Output frequency ≥ +L4-01 or output frequency ≤ -L4-01, detection width L4-02 used)
6-25
Setting
Value
Function Page
