Omron Varispeed E7 User Manual

User Parameter Tables
5-47
 Factory Settings that Change with the Inverter Capacity (o2-04)
200 V Class Inverters
Param-
eter
Number
Name Unit Factory Setting
– Inverter Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15
o2-04 kVA selection – 0 1 2 3 4 5 6 7 8
b8-04 Energy-saving coefficient – 288.20 223.70 169.40 156.80 122.90 94.75 72.69 70.44 63.13
C6-02
Carrier frequency
selection
*1
*1. The initial settings for C6-02 are as follows: 2: 5.0 kHz, 3: 8.0 kHz, 4: 10 kHz, 5: 12.5 kHz, and 6: 15 kHz. If the carrier frequency is set higher than the
factory setting for Inverters with outputs of 30 kW or more, the Inverter rated current will need to be reduced.
Normal Duty 1–666666666
Normal Duty 2–444346634
E2-01 Motor rated current A 1.90 3.30 6.20 8.50 14.00 19.60 26.60 39.7 53.0
E2-03 Motor no-load current A 1.20 1.80 2.80 3.00 4.50 5.10 8.00 11.2 15.2
E2-05 Motor line-to-line resistance W 9.842 5.156 1.997 1.601 0.771 0.399 0.288 0.230 0.138
L2-02
Momentary power loss ride through
time
sec. 0.1 0.1 0.2 0.3 0.5 1.0 1.0 1.0 2.0
L2-03 Min. baseblock (BB) time sec. 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
L2-04 Voltage recovery time sec. 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L8-02 Overheat pre-alarm level °C959595959595959595
L8-06 Input phase loss detection level % 5.0 7.5 10.0 12.0 12.0 10.0 17.0 21.0 17.0
Param-
eter
Number
Name Unit Factory Setting
– Inverter Capacity kW 18.5 22 30 37 45 55 75 90 110
o2-04 kVA selection – 9 A B C D E F 10 11
b8-04 Energy-saving coefficient – 57.87 51.79 46.27 38.16 35.78 31.35 23.10 23.10 23.10
C6-02
Carrier frequency
selection
*1
*1. The initial settings for C6-02 are as follows: 2: 5.0 kHz, 3: 8.0 kHz, 4: 10 kHz, 5: 12.5 kHz, and 6: 15 kHz. If the carrier frequency is set higher than the
factory setting for Inverters with outputs of 30 kW or more, the Inverter rated current will need to be reduced.
Normal Duty 1–666666666
Normal Duty 2–444346634
E2-01 Motor rated current A 65.8 77.2 105.0 131.0 160.0 190.0 260.0 260.0 260.0
E2-03 Motor no-load current A 15.7 18.5 21.9 38.2 44.0 45.6 72.0 72.0 72.0
E2-05 Motor line-to-line resistance W 0.101 0.079 0.064 0.039 0.030 0.022 0.023 0.023 0.023
L2-02
Momentary power loss ride through
time
sec. 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
L2-03 Min. baseblock (BB) time sec. 1.0 1.0 1.1 1.1 1.2 1.2 1.3 1.5 1.7
L2-04 Voltage recovery time sec. 0.6 0.6 0.6 0.6 0.6 1.0 1.0 1.0 1.0
L8-02 Overheat pre-alarm level °C959595959595959595
L8-06 Input phase loss detection level % 15.0 24.0 20.0 18.0 20.0 17.0 16.0 18.0 20.0
