îš‹ User Parameters Available in Quick Programming Mode
Commonly needed parameters for start-up of the Inverter can be monitored and set in the Quick Programming
Mode. Those parameters are listed in the following tables. All user parameters, including the Quick Program-
ming Parameters can be found in the Advanced Programming Mode as well.
îš„Quick Programming Parameters that are Always Available
Following table shows the parameter that are always available in Quick Programming Mode.
Parame-
ter Num-
ber
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
b1-01
Reference
source selection
Sets the frequency reference input
method.
0: Digital Operator
1: Control circuit terminal (analog input)
2: MEMOBUS communications
3: Option Card
0 to 3 1 No Q 180H
b1-02
RUN command
source selection
Sets the run command input method
0: Digital Operator
1: Control circuit terminal (digital multi-
function inputs)
2: MEMOBUS communications
3: Option Card
0 to 3 1 No Q 181H
b1-03
Stopping
method selec-
tion
Select stopping method when stop com-
mand is input.
0: Deceleration to stop
1: Coast to stop
2:DC braking stop (Stops faster than
coast to stop, without regenerative
operation.)
3: Coast to stop with timer (Run com-
mands are disregarded during deceler-
ation time.)
0 to 3 0 No Q 182H
b5-01
PI control mode
selection
0:Disabled
1:Enabled
3: PI control enabled (frequency refer-
ence + PI output)
When PI controller is enabled additional
parameters are available in Quick Pro-
gramming Mode and default values are
changed, refer to the following table.
0, 1, 3 0 No A 1A5H
C1-01
Acceleration
time 1
Sets the acceleration time to accelerate
from 0 Hz to the maximum output fre-
quency.
0.0 to
6000.0
10.0
sec.
Yes Q 200H
C1-02
Deceleration
time 1
Sets the deceleration time to decelerate
from the maximum output frequency to
0Hz.
Yes Q 201H
d2-01
Frequency ref-
erence upper
limit
Sets the frequency reference upper limit
as a percentage of the max. output fre-
quency.
0.0 to
110.0
100.0% No A 289H
d2-02
Frequency ref-
erence lower
limit
Sets the frequency reference lower limit
as a percentage of the maximum output
frequency.
0.0 to
110.0
0.0% No A 28AH
To Next Page
