User Parameter Tables
5-25
îš„Analog Inputs: H3
6
Inverter operation ready
READY: After start-up or no faults
6-65
7 During DC bus undervoltage (UV) detection 6-65
8 During baseblock (NO contact, ON: during baseblock) 6-65
9 Frequency reference source selection (ON: Frequency reference from Operator) 6-65
A Run command source selection status (ON: Run command from Operator) 6-65
B Load detection NO (NO contact, ON: overload/loss of load detected) 6-30
C Loss of frequency reference (Effective when 1 is set for L4-05) 6-44
E
Fault (ON: Digital Operator communications error or fault other than CPF00 and CPF01 has
occurred.)
6-65
F Not used. (Set when the terminal is not used.) -
10 Minor Fault (Alarm) (ON: Alarm displayed) 6-65
11 Fault reset command active 6-66
12 Timer function output 6-86
17 Load Detection NC (NC contact, OFF: overload/loss of load detected) 6-30
1A Reverse direction 6-66
1E Restart enabled (ON: Restart enabled) 6-45
1F
During motor overload (OL1, including OH3) pre-alarm
(ON: 90% or more of the detection level)
6-33
20 OH pre-alarm (temperature reached L8-02) 6-66
38 Drive enabled 6-66
39 Drive waiting (start delay time b1-11 is active) 6-66
3A During OH and reduced Frequency 6-66
3B RUN command from option card/communications 6-66
3D Cooling fan fault (ON: internal cooling fan error) 6-66
Parame-
ter Num-
ber
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
H3-02 Terminal A1 gain
Sets the frequency reference
value when 10 V is input as a per-
centage of the maximum output
frequency set in E1-04.
0.0 to
1000.0
100.0% Yes A 411H 6-21
H3-03 Terminal A1 bias
Sets the frequency reference
value when 0 V is input as a per-
centage of the maximum output
frequency set in E1-04.
-100.0
to
+100.0
0.0% Yes A 412H 6-21
H3-08
Analog input A2
signal level selec-
tion
Selects the signal level input at
multi-function analog input A2.
0: 0 to +10V (11 bit).
2: 4 to 20 mA (9-bit input).
3: 0 to 20 mA (9-bit input)
0, 2, 3 2 No
A
*1
417H 6-21
H3-09
Analog input A2
function selec-
tion.
Selects the multi-function analog
input function for terminal A2.
Refer to the table
H3-09 Set-
tings
for the explanation of the
setting range.
0 to 1F
2
*2
No
A
*1
418H 6-21
Setting
Value
Function Page
To Next Page
