6-26
Time Charts
The following table shows the time charts for each of the speed agreement functions.
Related parameter
L4-01: Speed Agree Level
L4-02: Speed Agree Width
f
ref
= f
out
Agree
f
ref
= f
out
Agree
f
out
= f
set
Agree
f
out
= f
set
Agree
(ON at the following conditions during frequency agree)
Frequency
Detection
Frequency (FOUT) Detection 1
(L4-01 > | Output frequency |)
Frequency (FOUT) Detection 2
(L4-01 < | Output frequency |)
L4-02
L4-02
ON
OFF
Output
Frequency
f
ref
= f
out
Agree
Freq. Ref.
Freq. Ref.
(Multi-function output setting = 2)
L4-01
L4-02
L4-01
L4-02
ON OFF
Output
Frequency
f
out
= f
ref
Agree 1
(Multi-function output setting = 3)
L4-01
L4-02
L4-01
L4-02
ON OFF
Output
Frequency
Freq. Detection 1
(Multi-function output setting = 4)
L4-01
L4-02
L4-01
L4-02
ON
OFF
Output
Frequency
Freq. Detection 2
(Multi-function output setting = 5)
