Individual Functions
6-97
Multifunction Digital Input Settings: H1-01 to H1-05 (Terminal S3 to S7)
PI Control Disable: 19
• When a multi-function digital input is set for this function it can be used to disable the PI function by
switching the input to ON.
• The PI target value becomes the frequency reference value.
PI Control Integral Reset: 30
• Using this function the integral value of the PI control can be reset by setting a multi-function digital input
to ON.
• It will remain at 0 as long as the input is ON.
PI Control Integral Hold: 31
• Using this function the integral share value of the PI control can be hold by setting a multi-function digital
input to ON. The value will be hold as long as the input is ON.
PI Soft Starter Disable: 34
• To disable the PI soft starter temporarily switch ON the multi-function digital input.
PI Input Characteristic Switch: 35
• Using this function the PI input characteristic can be inverted by switching the multi-function digital input
ON.
