9-4
îš„400 V Class Inverters in Protection Class IP54
Model Number
CIMR-E7Z

47P5 4011 4015 4018 4022 4030 4037 4045 4055
Max. applicable motor output
(kW)
*1
*1. The maximum applicable motor output is given for a standard 4-pole Yaskawa standard motor. When selecting the actual motor
and Inverter, be sure that the Inverter's rated current is higher than the motor's rated current.
7.5 11 15 18.5 22 30 37 45 55
Output Ratings
Rated output capacity
(kVA)
13 18 24 30 34 46 57 69 85
Rated output current (A)1724313945607591112
Max. output voltage (V) 3-phase; 380, 400, 415, 440, 460, or 480 VAC (Proportional to input voltage.)
Max. output frequency
(Hz)
200.0
Power Supply Characteristics
Rated voltage (V)
Rated frequency (Hz)
3-phase, 380, 400, 415, 440, 460 or 480 VAC, 50/60 Hz
Rated input current (A) 20 29 37 47 50 66 83 100 120
Allowable voltage fluctua-
tion
+ 10%, - 15%
Allowable frequency fluc-
tuation
±5%
Control Characteristics
Measures
for power
supply
harmonics
DC reactor Optional
Built in
12-phase rec-
tification
Not possible
To Next Page
