Omron Varispeed E7

2-12
Table 2.3 400 V Class Wire Sizes, IP54 Inverters
Inverter Model
CIMR-

Terminal Symbol
Ter mi -
nal
Screws
Tightening
Tor qu e
(N•m)
Recom-
mended
Wire Size
mm
2
(AWG)
Cable Gland
size
Possible
Clamp-
ing Cable
Diam.
(mm)
Minimum
Diam Over
Braid Shield
(mm)
E7Z47P52
INPUT (R/L1, S/L2, T/L3, )
M5 2.5 6 M32 (Plastic) 11 to 21 -
OUTPUT (U/T1, V/T2, W/T3, )
M4 1.8 6 M32 (Metal) 11 to 21 9.0
, 1
M4 1.8 6 - - -
E7Z40112
INPUT (R/L1, S/L2, T/L3, )
M5 2.5 10 M32 (Plastic) 11 to 21 -
OUTPUT (U/T1, V/T2, W/T3, )
M5 2.5 10 M32 (Metal) 11 to 21 9.0
, 1
M5 2.5 10 - - -
E7Z40152
INPUT (R/L1, S/L2, T/L3, )
M5 2.5 10 M32 (Plastic) 11 to 21 -
OUTPUT
U/T1, V/T2, W/T3 M5 2.5
10 M32 (Metal) 11 to 21 9.0
()
M6 4.0 to 5.0
, 1
M5 2.5 10 - - -
E7Z40182
INPUT (R/L1, S/L2, T/L3, )
M5 2.5 10 M32 (Plastic) 11 to 21 -
OUTPUT (U/T1, V/T2, W/T3, )
M6 4.0 to 5.0 10 M32 (Metal) 11 to 21 9.0
, 1
M6 4.0 to 5.0 10 - - -
E7Z40222
INPUT (R/L1, S/L2, T/L3, )
M6 4.0 to 5.0 16 M40 (Plastic) 19 to 28 -
OUTPUT
(U/T1, V/T2, W/T3) M6 4.0 to 5.0
16 M40 (Metal) 19 to 28 15.0
()
M8 9.0 to 10.0
, 1
M6 4.0 to 5.0 16 - - -
E7Z40302
INPUT (R/L1, S/L2, T/L3, )
M6 4.0 to 5.0 25 M40 (Plastic) 19 to 28 -
OUTPUT
(U/T1, V/T2, W/T3) M6 4.0 to 5.0
25 M40 (Metal) 19 to 28 15.0
()
M8 9.0 to 10.0
, 1
M6 4.0 to 5.0 25 - - -
E7Z40372
INPUT (R/L1, S/L2, T/L3, )
M8 9.0 to 10.0 35 M50 (Plastic) 19 to 28 -
OUTPUT
(U/T1, V/T2, W/T3) M8 9.0 to 10.0
35 M50 (Metal) 19 to 28 -
()
M8 9.0 to 10.0
, 1
M8 9.0 to 10.0 35 - - -
E7Z40452
INPUT (R/L1, S/L2, T/L3, )
M8 9.0 to 10.0 35 M50 (Plastic) 19 to 28 -
OUTPUT
(U/T1, V/T2, W/T3) M8 9.0 to 10.0
35 M50 (Metal) 19 to 28 -
()
M8 9.0 to 10.0
, 1
M8 9.0 to 10.0 35 - - -
E7Z40552
INPUT (R/L1, S/L2, T/L3, )
M8 9.0 to 10.0 50 M50 (Plastic) 19 to 28 -
OUTPUT
(U/T1, V/T2, W/T3) M8 9.0 to 10.0
50 M50 (Metal) 19 to 28 -
()
M8 9.0 to 10.0
, 1
M8 9.0 to 10.0 50 - - -
Table 2.4 Recommended Wire Types for IP54 Inverters
INPUT
4-core Power Cable
*1
*1. 4-core power cables or 4-core shielded power cables are available e.g. Lappkabel (Ölflex) or Pirelli
OUTPUT
4-core shielded Power Cable
*1
(-), (+1) e.g. 600V Vinyl Power Cable
