Omron Varispeed E7 User Manual

2-14
Recommended Crimp Terminals
Table 2.6 Recommended Crimp Terminals
Wire Cross Section
(mm²)
Terminal Screws
Recommended Crimp Terminals
Klaukey
JST
a b
0.5-1.0 M4 620/4 1620/4 GS4-1
1.5 M4 630/4 1620/4 GS4-1
2.5 M4 630/4 1630/4 GS4-2.5
4 M4 650/4 1650/4 GS4-6
6
M4 650/4 1650/4 GS4-6
M5 101 R/5 1650/5 GS5-6
M6 101 R/6 1650/6 GS6-6
M8 101 R/8 1650/8 GS8-6
10
M5 102 R/5 1652/5 GS5-10
M6 102 R/6 1652/6 GS6-10
M8 102 R/8 1652/8 GS8-10
16
M5
103 R/5
*1
*1. not applicable for E7Z2011
1653/5 GS5-16
M6 103 R/6 1653/6 GS6-16
M8 103 R/8 1653/8 GS8-16
25
M6 104 R/6 1654/6 GS6-25
M8 104 R/8 1654/8 GS8-25
35
M6 105 R/6 1655/6 GS6-35
M8 105 R/8 1655/8 GS8-35
M10 105 R/10 1655/10 GS10-35
50
M8 106 R/8 1656/8 GS8-50
M10 106 R/10 1656/10 GS10-50
M12 106 R/12 1656/12 GS12-50
70
M8 107 R/8 1657/8 GS8-70
M10 107 R/10 1657/10 GS10-70
M12 107 R/12 1657/12 GS12-70
95
M10 108 R/10 1658/10 GS10-95
M12 108 R/12 1658/12 GS12-95
M16 108 R/16 1658/16 GS16-95
120
M12 109 R/12 1659/12 GS12-120
M16 109 R/16 1659/16 GS16-120
150
M12 110 R/12 1660/12 GS12-150
M16 110 R/16 1660/16 GS16-150
240
M12 112 R/12 1662/12 GS12-240
M16 112 R/16 1662/16 GS16-240
300 M16 113 R/16 - -
