3-18
Example Operations with LCD Digital Operator
Fig 3.15 shows an example for an Autotuning procedure with LCD Digital Operator
Fig 3.15 Operation in Autotuning Mode with LCD Digital Operator
IMPORTANT
If a fault occurs during autotuning, refer to Chapter 7, Troubleshooting.
ESC
ESC
ESC
Mode Selection Display
Autotuning
Monitor Display
Setting Display
MENU
MENU
MENU
MENU
MENU
** Main Menu **
-QUICK-
Quick Setting
** Main Menu **
-DRIVE-
Operation
** Main Menu **
-A.TUNE-
Auto-Tuning
** Main Menu **
-VERIFY-
Modified Consts
** Main Menu **
-ADV-
Programming
Rated Current
-A. TUNE-
(0.32~6.40)
- 04 = 1.90A
T1
"1.90A"
Mtr Rated Power
-A. TUNE-
(0.00~650.00)
- 02= 0.40kW
T1
"0.40kW"
Mtr Rated Power
-A. TUNE-
(0.00~650.00)
- 02=000.40kW
T1
"0.40kW"
Rated Current
-A. TUNE-
(0.32~6.40)
- 04 =001.90A
T1
"1.90A"
ESC
Auto-Tuning
-A. TUNE-
Tuning Ready ?
Press RUN key
0Hz/ 0.00A
Rdy
Auto-Tuning
-A. TUNE-
START > > > GOAL
0Hz/ 0.38A
Rdy
RUN
STOP
Tune Aborted
-A. TUNE-
STOP key
Tune Successful
-A. TUNE-
0Hz/ 0.00A
