Section 5 Setting Judgement Output Timing (Timer)
Section 5
DETAILED SETTINGS
The following description uses the OFF-delay timer as an example. Make the neces-
sary adjustments if other timers are used.
Moving to FUN mode and TIMER
1. Set the mode switch to FUN.
2. Use the LEFT and RIGHT Keys to display
TIMER on the main display.
Selecting Timers
3. Press the UP or DOWN Key.
The sub-display will flash.
4. Use the UP and DOWN Keys to select the
timer.
5. Press the ENT Key to confirm the selection.
The selected timer will be registered.
If anything other than OFF is selected, use the following
procedure to set the timer time.
Setting Timer Time (when a Timer Is Selected)
6. Use the LEFT and RIGHT Keys to display T-
TIM on the main display.
T- T I M
cannot be displayed if OFF is selected.
7. Press the UP or DOWN Key.
The leftmost digit on the sub-display will flash.
