147
ZX-E
Operation Manual
Appendices
Specifications and Dimensions
APPENDICES
Power supply voltage 12 to 24 VDC ±10%, Ripple (p-p) 10% max.
Supplied from Amplifier Unit
Current consumption Power supply voltage: 12 V, Current consumption: 60 mA max.
(Excluding Amplifier Unit current consumption and output current.)
Connectable Amplifier Units ZX Series
No. of Amplifier Units con-
nectable
Up to 5 (Two Calculating Units max.)
Communica-
tions functions
Communica-
tions port
RS-232C port (9-pin D-sub connector)
Protocol CompoWay/F
Baud rate 38,400 bps
Data config-
uration
Data bits: 8, Parity: None; Start bits: 1
Stop bits: 1, Flow control: None
Indicators Power ON (green), Communicating with Sensor (green), Sensor communications
error (red)
Communicating with external terminal (green), External terminal communications
error (red)
Protection circuits Reverse power supply wiring protection
Ambient temperature Operating: 0 to 50
°C, Storage: −15 to 60°C (with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Dialectic strength 1,000 VAC, 50/60 Hz for 1 min
Insulation resistance 20 M
Ω min. (at 500 VDC)
Case materials Case: PBT (polybutylene terephthalate), Cover: Polycarbonate
Weight (packed state) Approx. 350 g
